PAN Graphite Felt
High-Temperature Resistance – Withstands up to 3000°C.
Mechanical Strength – Excellent rigidity and durability.
Chemical Stability – Resists harsh environments.
Low Thermal Conductivity – Effective insulation, improving energy efficiency.
Customizable – Available in 3MM, 5MM, 10MM thicknesses.
Description
Introductory Overview
PAN graphite felt is a high-performance material designed for demanding high-temperature environments. Known for its superior strength, thermal insulation properties, and chemical stability, it is a reliable choice for industries that require precise thermal control and durability. Whether in vacuum furnaces, semiconductor production, or solar photovoltaic manufacturing, PAN graphite felt ensures consistent temperature control and energy efficiency under extreme conditions.
At SHJ CARBON, we have over 25 years of experience providing premium materials to industries that demand exceptional performance. Our PAN graphite felt solutions are trusted by leading manufacturers worldwide for their reliability, long service life, and precision. As an industry leader, we are committed to delivering customized thermal insulation materials that support the specific needs of your high-temperature processes.
What Is PAN Graphite Felt?
PAN graphite felt is a high-performance insulation material made from polyacrylonitrile (PAN) fibers that are carbonized and coated with graphite. This process creates a rigid yet flexible material that combines excellent thermal insulation with mechanical strength, making it ideal for high-temperature applications.
Manufacturing Process
PAN graphite felt is produced through a specialized process that involves carbonizing PAN fibers at high temperatures, followed by graphite coating. This enhances the material's ability to withstand extreme temperatures, making it the preferred choice for vacuum furnaces, heat treatment systems, and other high-heat environments.
Comparison with Rayon Graphite Felt
PAN graphite felt is stronger and more rigid than rayon graphite felt, offering superior mechanical strength and oxidation resistance. While rayon graphite felt is ideal for flexible applications, PAN graphite felt excels in high-pressure, high-temperature environments where structural stability is critical.
At SHJ CARBON, our experienced engineers understand the specific requirements of different operating conditions and temperatures. If you're unsure which type of graphite felt is best suited for your application, we are here to provide professional material recommendations. Additionally, we offer custom solutions to ensure your needs are met, optimizing performance and efficiency for your specific industrial processes.
Key Features & Benefits
High Thermal Resistance
PAN graphite felt can withstand temperatures up to 3000°C, making it perfect for high-heat applications like vacuum furnaces and sintering processes.
Superior Strength and Durability
Its rigid structure provides excellent mechanical strength, ensuring reliable performance in high-pressure environments.
Chemical Resistance
PAN graphite felt is resistant to harsh chemicals, making it ideal for semiconductor manufacturing and other industries where exposure to corrosive materials is common.
Low Thermal Conductivity
This material effectively reduces heat loss, improving energy efficiency in high-temperature furnaces and thermal insulation systems.
Customization Options
Available in various thicknesses and sizes, PAN graphite felt can be tailored to meet the specific needs of your applications, whether for vacuum chambers or high-temperature insulation.
TAICHIRON@ Series Technical Specifications
| Product | Bulk Density | Thermal Conductivity (@1000℃) |
Ash Purification |
Operating Temperature |
Available Sizes |
| PAN-Based | 0.13g/cm³ | 0.2W/(m.k) | ≤20ppm | ≥2000℃ | 10x1200*20000mm 5x1200*20000mm |
| PAN-Based | 0.15g/cm³ | 0.15W/(m.k) | ≤20ppm | ≥1800℃ | 3x1500*20000mm 10x1200*20000mm |
Applications of Rayon Graphite Felt
High-Temperature Environments and Energy Storage
PAN graphite felt is widely recognized for its exceptional oxidation resistance and high performance in environments with temperatures ranging from 2800°C to 3000°C. This makes it a preferred material for flow battery electrodes, where it plays a key role in providing thermal insulation and enhancing the overall efficiency of energy storage systems. Additionally, PAN graphite felt is heavily utilized in the solar photovoltaic industry, especially in silicon crystal manufacturing. It ensures stable heat distribution during crystal growth processes, maintaining the necessary thermal stability in high-temperature furnaces.
Semiconductor and High-Strength Industrial Applications
In semiconductor production, PAN graphite felt provides crucial thermal insulation in vacuum furnaces and crystal growth systems, where precise temperature control is essential for high-quality results. The material's resilience to oxidation and its ability to maintain structural stability in extreme conditions make it ideal for use in other high-performance industries, including aerospace and metallurgy. In these fields, PAN graphite felt ensures consistent heat control, contributing to product quality and process reliability in high-temperature, high-strength environments.
Why Choose SHJ CARBON for PAN Graphite Felt?
Technology First
With years of expertise in providing advanced thermal insulation solutions, SHJ CARBON offers:
Customized Solutions
Tailored PAN graphite felt for your specific furnace or high-temperature process.
Proven Reliability
Trusted by top manufacturers in industries like semiconductor production, aerospace, and solar energy.
Strict Quality Control
Our products undergo rigorous testing to ensure they meet the highest performance standards.
Expert Engineering Support
We provide expert advice and product customization to ensure the best fit for your operational needs.
FAQs – Rayon Graphite Felt
PAN graphite felt is a high-performance material made from polyacrylonitrile (PAN) fibers that are carbonized and coated with graphite. This combination provides exceptional thermal insulation, oxidation resistance, and mechanical strength, making it ideal for high-temperature applications such as vacuum furnaces, semiconductor production, and solar photovoltaic processes.
PAN graphite felt performs excellently in extreme heat environments, withstanding temperatures up to 3000°C without degradation. Its low thermal conductivity ensures effective heat retention, while its oxidation resistance makes it ideal for use in high-temperature environments where other materials may break down. The material also exhibits thermal shock resistance, maintaining its structural integrity even during rapid temperature fluctuations.
Yes, PAN graphite felt is highly customizable. It is available in various thicknesses (3MM, 5MM, 10MM) and can be cut into custom shapes and sizes to fit specific applications. Whether you need it for vacuum furnaces, heat treatment systems, or semiconductor processes, we can tailor the material to meet your exact requirements.
PAN graphite felt is widely used across industries that require high-performance thermal insulation. Key industries include:
- Electronics manufacturing (for circuit board sintering and wafer processing)
- Semiconductor production (for crystal growth and vacuum furnaces)
- Aerospace (for components exposed to extreme heat, like turbine blades and heat shields)
- Solar photovoltaics (for use in polycrystalline casting furnaces and single-crystal growth systems)
- Metallurgy (for sintering and brazing processes)
The service life of PAN graphite felt in high-temperature environments can range from several years to thousands of cycles, depending on the specific operating conditions and temperature levels. Its longevity is significantly enhanced when properly maintained and used in controlled environments. Surface treatments like edge sealing and corrosion resistance can further extend the material's lifespan.
