Good Heat Resistance Vibration Graphite Material
Vibration graphite materials from graphite manufacturer SHJ have good heat resistance and other good properties.
Description
Specialty Graphite: Vibration Graphite blocks
Vibratory molding is a special carbon forming method unique to the early days of the graphite industry in China, which has been gradually improved and is now used in large-scale mass production.
Vibration graphite is produced by injecting a carbon paste into a forming mold, and then vibrating the paste inside the mold with strong vibration to achieve dense molding. It is characterized by its ability to produce graphite in larger sizes than conventional molded materials, which meets customer demand for large-size specialty carbon materials.
In recent years, Vibrated graphite materials have been increasingly used as an alternative to large-size extruded graphite square materials.
Applications
graphite boxes for the production of anode;
heat exchangers;
exothermic welding;
and more.
specifications
|
Grade |
MV-12 |
MV-13 |
MV-20 |
|
|
Type of Forming |
Unit |
Vibro-molded |
Vibro-molded |
Vibro-molded |
|
Bulk Density |
g/cm³ |
1.72 |
1.73 |
1.65 |
|
Specific Resistance |
μΩ.m |
9 |
8.5 |
11 |
|
Compressive Strength |
MPa |
30 |
35 |
28 |
|
Flexural Strength |
MPa |
13 |
15 |
9 |
|
C.T.E(RT-600℃) |
10-6/℃ |
3.2 |
3.3 |
N/A |
|
Thermal Conductivity |
W/(m.k) |
100 |
130 |
N/A |
|
Ash |
% |
0.2 |
0.12 |
0.25 |
|
Maximum Grain Size |
mm |
0.8 |
0.8 |
2 |
|
Regular Size |
Blocks: 500*500*(1800/1850), 650*(500/600)*(1800/1850/2200), 800*500*1850, 950*500*1850, 1100*400*2200, 1250*450*2200. |
|||
|
The above properties are typical values, not guaranteed, other specifications are available. |
||||
